DMX-S8

The DMX-S8 is an 8-way RS-485 and power splitter designed for fixed installations.

It can be used as a hub for DMX512-A signals to simplify wiring or to extend the reach of a DMX universe.

It features an isolated receiver with a passive THRU port.

Product Enquiry

Features

  • DMX512-A Compatible
  • Isolated Receiver
  • Jumper Selectable Termination
  • DMX THRU Terminal (Passive Loop)
  • DIN-Rail Mounting Kit (Optional)

Application

  • Extending the reach of a DMX Universe

Specifications

ParameterDescription
Supply Voltage12 to 24 VDC (+/- 10%)
Power Consumption1 Watt (max)
Max. Current (per Load)3A
Max Current (Total)16A
Max. RS-485 Signaling Rate250 kHz
Isolated ReceiverYes
DMX THRUYes (Passive Loop)
Operating Temperature0 to 50 degC
LED IndicationNone
Dimensions5.5″ x 2.875″
Weight250g
Warranty1 Year (Limited Warranty)

Ordering Information (Part Numbers)

  • DMX-S8 REV A1 – 8-Way RS-485 & Power Splitter Module
